Basic Info.
Product Description
Stainless Steel 304 For Airport Yard Cleaning
Cleaning Street Road Sweeper Truck Ask for better price
1> Equipped with 4 sweeping brush, JMC 88hp deputy engine; Italian motor; French control switch; Joint venture solenoid valve group; Maintenance-free self-separate clutch; Maintenance-free fan; Stainless steel water tank and dustbin; Rear LED arrow lights, manual pump for emergency system.
2> Maximum sweeping width 3.2 m, inhaled sizeφ120 mm
3> Optional: monitoring, sprinkler function, self-cleaning function for dustbin.
The pictures are for your reference only.
Product Application
suzu Sweeper Truck , with suzu truck chassis , 1.2 cbm water tanker volume and 4 cbm debris , four main broom ( broom has 3 speed control ) , I.S.U.Z.U sub-engine , maintenance free clutch and fan .
Normally used in Airport , Factories , Countries , Event place , Stadiums , Hospital , Buildings , Power Plants , Collages , Parks , Schools , Highways , Cities , Ports , Parking decks , Malls , Paved trails , Construction etc.
Our Advantages
1) Advanced hydraulic : Generate power and reliability where you need most
2) Customized Application --dual steering , custom painting we can build your perfect unit .
3) Innovative controls user friendly controls customized for operators .
4) Drive Friendly simple operation , training and no CDL requirements.
SPECIFICATION
road sweeper truck china for sales
Compared with common road sweeper, this model has more functions:Road sweeping, road flushing, multi-angle slush flushing, separation zone cleaning, freeway guard rail flushing,spraying, moistening and dust containing, high pressure water gun for car cleaning/low flat flushing with strong water flow, road sprinkling and flower watering from both sides and so on.
1.The Vice-engine sweepers no. Fans and other work devices to take power through the chassis engine to drive.
2. Cleaning device with Automatic Collision Avoidance Obstacle protection and automatic reset function (by national patent)
3. "Mid four brush - rear nozzle" structure layout with sweeping wide, clean and efficient features, and facilitate the cleaning device and nozzle adjustment and maintenance.
4.Pneumatic conveying system with digestion and absorption of foreign advanced technology and efficient sweepers dedicated fans and can auto-leveling with the road the whole floating nozzle.
5.Sweeper combined with trochar disc, it can work excellently and can automotically choose work type according to waste condition on the ground and speed of the truck. ;
6.Trash and water tank large, continuous cleaning operation a long time.
7. Left, right front linkage scan can work independently or can choose to use the right front or left front sweep sweep to work independently.
8.Hydraulic system with superimposed solenoid hydraulic valve, highly integrated, reliable, easy maintenance;
9. Control switch installed in the driver focused interior, all electronic control can be found in cab ,Beautiful appearance designed via computer.
ITEM | UNIT | PARAMETER | ||||
Vehicle model | DRZ5070TSLH4 SUZU SWEEPER TRUCK | |||||
| GVW | Kg | 6995 | |||
Payload | 1900 | |||||
Curb weight | 4965 | |||||
Axle load | 2520/4475 | |||||
Overall dimension | mm | 5900×1980×2450 | ||||
Body dimension | ×× | |||||
Wheelbase | 3360 | |||||
Front/Rear overhang | 1105/1435 | |||||
Front track base | 1440 | |||||
Rear track base | 1425 | |||||
Approach/departure angle | ° | 24/14 | ||||
Exhaust/hp | ml/kw | 2771/88 | ||||
Max speed | km/h | 90 | ||||
Chassis model | suzu ELF | Manufacturer of chassis | suzu Automobile Co.,Ltd | |||
Engine model | suzu 4JB1CN | Manufacturer of Engine | suzu Automobile Co.,Ltd | |||
Fuel tank capacity | Appro.X180L | Brake system | Pneumatic | |||
Engine fuel type | Diesel | Tire specification | 7.00-16 | |||
Tires Nos. | 6+1 | Pieces of spring | 7/4+5 | |||
Traction system | 4×2 | Transmission | 5-speed | |||
Operation control system | Electrically hydraulic control | Allowable passengers in cab | 3 | |||
Emission standard | GB3847-2005,GB17691-2005 Euro 3-5-6 | |||||
Techinical parameters | Auxiliary engine | CY4100/JX493G | ||||
Max cleaning width (mm) | 3300-3500 mm | |||||
(PM 10)Cleaning efficiency | >96% | |||||
Max cleaning speed (km/h) | 5-15 km/h | |||||
Max tipping angle (°) | 45° | |||||
Max suction granularity (mm) | 50 | |||||
Water tank capacity (M3) | 1.0 | |||||
Garbage tank capacity (M3) | 4.5 | |||||
suction diameter | Φ200 import | |||||
Special blower | 800-1100-2900N | |||||
cleaning operation fuel consumption | <3 | |||||
Oil Pump Volume | 25 L/M | |||||
Motor Displacement | 16L | |||||
,
Intermediate 4 sweepers, rear suckers, carbon steel water tank, stainless steel garbage bin;
*Jiangling 77 horsepower sub-engine/Cummins 140 horsepower sub-engine, German Siemens control switch, high quality solenoid valve group
*Two-way operation button, Sanyo motor and high quality diaphragm pump, continuously variable speed automatic clutch
*Maintenance-free centrifugal fan, wear-resistant cylinder, manual pump emergency system, precision cold-formed Seamless Hydraulic tubing, tail LED arrow lamp.
*The cleaning width was 2.6-3.5M and the inhalation particle size is Φ 120 mm
suzu Road sweeper truck is also called road sweeper truck, it combine the function of road sweeping, garbage collection and garbage transportation , is new type efficient sanitation special cleaning vehicle
SUZU 4cbm dustbin floor sweeper, street sweeper truck for sale
we commit to kinds of sweeper truck with different chassis, any inquiry please contact us.thank you.
Vehicle model | DRZ5073TSLHF |
Tank fact cubage(cbm) | 4m3 dustbin,1.5m3 clean water tank |
Chassis model | NKR1071 |
Maximum total mass | 6995kg |
Curb weight | 4965kg |
Load weight | 1900kg |
Effective volume | 5-7m³ |
Dimensions | 6190×1990×2590 (mm) |
Garbage box capacity | 4CBM |
Wheelbase | 3360 mm |
| Cab | 2 or 3 passengers |
Tyre Specfication | 7.00-16 |
Paint | Automative metallic paint |
Equipment
| 1> Equipped with 4 sweeping brush, JMC 88hp deputy engine; Italian motor; French control switch; Joint venture solenoid valve group; Maintenance-free self-separate clutch; Maintenance-free fan; Stainless steel water tank and dustbin; Rear LED arrow lights, manual pump for emergency system. 2> Maximum sweeping width 3.2 m, inhaled sizeφ120 mm 3> Optional: monitoring, sprinkler function, self-cleaning function for dustbin. |
Street Sweeping 4 Brooms Vacuum Cleaner Steel Brush Multifunction Road Sweeper Truck
Debris Bin And Water Bin Are Made Of Stainless Steel ,Corrosion-Resistant
Four Booms Sweeping System And Suction System Combine Working ,High Efficient.
Water Sprinklers Equipped On Brooms,Suction Nozzle.
Suction Nozzle Is Floating Type,Self Adjustable For Different Road Condition.
Air Blower Is Special For Road Sweeper,High Efficient,Low Noise
4x2 Howo road sweeper truck street sweeper truck vacuum road sweeper
Sinotruk HOWO light truck road sweeper truck hot sale factory price1.production name:road truck, road sweeper truck, road sweeping truck,road sweeper machine,road sweeper,road sweeper vehicle,road sweeper car.
2.driving style:4x2 ,4x4, 6x4, 6x6, 8x4 ,8x8
3.Provide different brand chassis: DONGFENG, SINOTRUK, SHACMAN, NORTH BENZ, FOTON, ROWOR, HINO, JAC, JMC
OR WITH JAPAN CHASSIS
1. Consist of origina Vehicles chassis, hydraulic system, elevating system and electrical system.
2. Sweeper Truck technology from American and made a lot of optimized design.
3. The cleaning system is driven by imported advanced hydraulic motor to guarantee the power and reliability during work.
4. With the structure of four mid-mounted disk brushes and one rear-mounted suction nozzle, which provide a large sweeping width, high sweeping efficiency and good traffic ability. Also convenient for adjustment and maintenance of sweeper device and nozzle.
5. An automatic clutch is set up on the transmission between the vice-engine and the fan, wshich can ensure the automatic separation of the vice-engine from the fan when the vice-engine startup or shutdown.
6. The sweeping disk has the protection function and automatic reset function, which can avoid obstacles automatically and return automatically.
Beiben road sweeper truck
maximum operation capacity: sqm/h/h-44000 -90000square meters.
| Standard configuration Chassis,sub frame,body,4 sweeping brushes, stainless steel vacuum tank, water tank,5T fan, auxiliary engine, electromagnetic control valve, suction cup, sprinkler system, hydraulic system and electrical system. Selective configuration surveillance system,rolling brush. | |||||||||||
| Vehicle model | Chassis brand | Chassis model | Load (L) | Overall dimensions | Wheel base | Engine model | hp/standard | Tire | EXW Price RMB /USD=6.3 | ||
| Dust | Water | mm | mm | RMB | USD | ||||||
| DRZ5160TSLD | DONGFENG LHD/RHD RHD price add $2000 | DFL1160BX | 6000;7000 | 4000; 3500 | 8090X2470X3050 | 4700 | B190 33 | 190/Euro 3 | 9.00-20 | 309800 | US$49,175 |
| DRZ5060TSLE | DONGFENG LHD/RHD RHD price add $2000 | EQ1060TJ20D3 | 3500 | 800 | 5970X2000X2400 | 3300 | CY4102-C3F | 95/Euro 3 | 11.00R20 | 159400 | US$25,302 |
| DRZ5090TSLE | DONGFENG LHD/RHD RHD price add $2000 | EQ1090T9ADJ3AC | 4500 | 1000 | 6700X2290X2500 | 3800 | CY4102-E3C | 120/Euro 3 | 7.50R16 | 200500 | US$31,825 |
| DRZ5108TSLE | DONGFENG LHD/RHD RHD price add $2000 | EQ1108KJ | 5000 | 3000 | 7000X2480X3000 | 3950 | B170 33 | 170/Euro 3 | 9.00-20 | 257700 | US$40,905 |
| DRZ5126TSLE | DONGFENG LHD/RHD RHD price add $2000 | EQ1126KJ1 | 6000 | 4000 | 8090X2470X3050 | 4700 | B190 33 | 190/Euro 3 | 9.00-20 | 279800 | US$44,413 |
| DRZ5141TSLE | DONGFENG LHD/RHD RHD price add $2000 | EQ1141KJ | 6000 | 4000 | 7650X2480X3000 | 4500 | B190 33 | 190/Euro 3 | 10.00-20 | 272700 | US$43,286 |
| DRZ5073TSLB | FOTON LHD/RHD RHD price add $2000 | BJ1073VEJEA-A | 3500 | 800 | 5995X1900X2680 | 3360 | 4DW91-63NG2 | 98/Euro 2 | 6.50-16 | 149400 | US$23,714 |
| DRZ5163TSLB | FOTON LHD/RHD RHD price add $2000 | BJ1163VKPGG-1 | 6000 | 4000 | 7810X2495X3160 | 5000 | Phaser160Ti-33 | 160/Euro 3 | 9.00R20 | 299800 | US$47,587 |
| DRZ5070TSLQ | SUZU LHD | ||||||||||
| SUZU LHD | QL11009LARY | 5000 | 3000 | 6910X2200X2640 | 4175 | 4HK1-TCG40 | 190/Euro 4 | 8.25-20 | 331400 | US$52,603 | |
| DRZ51609TSLQ | SUZU LHD | QL11609MFRY | 6000 | 4000 | 7705X2500X3060 | 4500 | 4HK1-TCG40 | 190/Euro 4 | 10.00-20 | 403100 | US$63,984 |
| DRZ5161TSLH | JAC LHD/RHD RHD price add $2000 | HFC1161P3K2A47F | 6000 | 4000 | 8155X2495X3070 | 4700 | YC4E160-42 | 160/Euro 4 | 11.00R20 | 337900 | US$53,635 |
| DRZ5165TSLS | SHACMAN LHD/RHD RHD price add $2000 | SX1165UN461 | 6000 | 4000 | 8040X2490X3270 | 4600 | WP10.270E32 | 270/Euro 3 | 12.00R20 | 362000 | US$57,460 |
